U-Lite™ CanopiesCanopies with monolithic polycarbonate glazing for low-slope applications.
)
)
)
)
)
)
Product Information
U-Lite™ systems feature a slim profile that gives the system a sleek, contemporary look. And with available transparent polycarbonate glazing that can replicate the look of glass, you can create an eye-catching design without the extra cost or weight of more traditional glazing. U-Lite™ canopies are also designed without a perimeter frame, giving an exposed floating edge. The lightweight panels are easy to install, and the glazing material is inherently flexible so it will not shatter upon high impact - making them extremely durable and ensuring longevity and minimizing maintenance costs.
Product Highlights
- Engineered for, but not limited to, canopies designed with a pitch minimum of ½”:12
- Systems utilize a 4mm thick monolithic standing seam glazing panel and are designed without a perimeter frame - optional enclosed edge is available
- Lightweight system for fast, easy installation
- Wide range of glazing colors with translucent and transparent options available
- Can accommodate both standard and flared end designs
- Glazing panels are extremely durable and resistant to high impact
- Aluminum glazing bars enable larger spans, which can reduce both material and labor costs
- Systems available for high velocity hurricane zones (HVHZ)
- Co-Extruded UV protection integrated within the glazing for superior color stability
Technical Information
Dimensions
- Thickness: 4 mm
- Panel Width: 2 ft nominal (600 mm)
- Minimum Slope: 1/2:12
- Panel Weight: 1.5 to 2lbs/ft2
- Rafter Size: 3" wide x 2-3/4" tall - 24" O.C. spacing
- Panel Joint: Mechanically standing seam connection
- Standard Glazing Colors (Gloss finish): Clear, White Ice, White Opal, Light Blue, Light Green, Dark Bronze, Solar Grey, Dark Grey
(Contact us for other available color options)
Certifications & Test Results
- Florida Product Approval - FPA#: FL47324, HVHZ Approved, TAS 202 + 203 - Up to +/-150psf
- TX Dept. of Insurance - TDI - FL-20323
- Fall Protection - ASTM E 661 in reference to OSHA: 1926.502(i)(2), and/or CalOSHA: Sections 1632(b)(3), 3212(b) - 800lb. Concentrated Load
- Fire Testing - Flame Spread & Smoke Developed, ASTM E 84, Class A / Burning Rate, ASTM D 635, CC1 / Ignition Temp, ASTM D 1929, Pass / Smoke Development, ASTM D2843, Pass
Downloads
Brochure
Specification Text
Sustainability (EPD, FDS..)
U-Lite™ Canopies
Optimized for low slope applications
U-Lite™ is a great choice for low sloped designs (1/2:12 and above), and is available in a variety of custom colors and configurations.
U-Lite™ systems are also available with a clear glazing option that mimics glass but with less weight and cost.
)
Frequently Asked Questions
Am I limited to standard sizes and configurations?
U-Lite™ low slope canopies are custom designed to your project’s specific demands – contact us with questions and we can help you get started with a design that will fit your needs.
What glazing colors are available?
Options for low slope canopies include white, ice white, refl. gray, blue, green, bronze, and clear, as well as custom colors. Contact is for details on custom options.
How can I create the look of a glass skylight with polycarbonate glazing?
U-Lite™ low slope canopies are available with a clear polycarbonate glazing option that closely mimics the look of glass but with less weight and cost. Transparent and translucent glazing can also be inter-mixed to create an eye-catching design.
What pitch is considered low slope?
U-Lite™ canopy systems are a great choice if your slope has a pitch minimum of 1/2":12. Contact us if you need clarification on the best system for use with your project.
What king of maintenance is required for these canopy systems?
U-Lite™ canopies only require normal cleaning and maintenance to maintain their performance.
